Uni-T UT262E Non-Contact Phase Sequence Detector

Name: Uni-T UT262E Non-Contact Phase Sequence Detector
Brand: UNI-T
SKU: 58137-uniw
Price: 101.5 EUR
Availability: InStock

101,50 €

AR PVN

Ir Noliktavā

Product Parameters

Gross weight	390
Net weight	237
HS Code	9030310090
Quantity per carton	5 pcs.
Box length	17,50
Box width	17,00
Box height	6,50

Uni-T UT262E Non-Contact Phase Sequence Detector

The UT262E is a non-contact phase detector in a clamp-on design, engineered for safe operation on three-phase systems without the need to touch exposed wires. This reduces the risk of electrical arcing and minimizes the danger of electric shock during field work. The device allows for quick verification of phase presence, identification of phase sequence, detection of phase loss, and localization of wire breaks, utilizing both audible and visual signals. It is ideal for service work, motor installation, and electrical system maintenance.

Included

Phase sequence detector
2 AA batteries
Carrying case
User manual
Warranty card
Inspection certificate

Specifications

Manufacturer	Uni-T
Model	UT262E
Type	Non-contact phase sequence detector
Measurement method	Non-contact (inductive clamps)
Voltage range	70~1000V AC
Operating frequency	45~66 Hz
Functions	Phase detection / phase loss / phase sequence / open circuit detection
Cable diameter	Ø2~40 mm
Cable length	0.6 m
Signaling	LED + buzzer
Signal volume	65~70 dB
Auto-off	After approx. 5 minutes
Operating time	Over 20 hours
Safety class	CAT III 1000V / CAT IV 600V
Protection rating	IP52
Power supply	2 × AA 1.5V
Weight	237.7 g (with batteries)
Dimensions	88 × 30 × 66 mm
Certifications	CE, UKCA
